SG-TF-S-135W

Sungold etfe solar panel TF-S-135W

Polymer composite material /SunPower solar cells/5 years warranty
The TF-S-135W semi flexible solar panel features SunPower cells that boast an impressive conversion efficiency of up to 24%. This makes it an excellent choice for various applications such as RVs, ships, yachts, BIPV, and more. The patented materials used by Sundold provide better cell protection and absorb impact forces more efficiently.
Moreover, the TF-S-135W flexible solar panel is highly flexible, making it easy to install on uneven surfaces. Its ETFE surface material ensures exceptional weather, salt spray, corrosion, and aging resistance, ensuring optimal performance for many years to come.
make the most of every sunlight
Features
Exclusive Patented Material
Lighter And Thinner
Easy To Use
High Conversion And Corrosion Resistance
Exclusive Patented Material
The TF-S-135W marine flexible solar panel features Sungold’s proprietary patented material combined with SunPower solar cells to create an outstanding product. This exclusive material significantly improves weather resistance, salt spray resistance, corrosion resistance, and anti-aging properties, providing superior protection for the solar cells. Additionally, the material enhances the absorption of impact force, thereby minimizing damage to the solar cells.
Lighter And Thinner
TF-S-135W flexible solar panel is very light and thin, weighing only 2.33 kg with a thickness of only 2mm. It is very suitable for installation on RVs or in marine environments, and has flexibility and portability.
HIGHER POWER
The flexible solar panels utilize back-contact SunPower cells, which have a maximum power output of 90W and an efficiency rating of up to 22.4% to 24%. These panels demonstrate excellent performance in low-light conditions, ensuring that they can still provide adequate power support for you even during such conditions.
HIGH CONVERSION AND CORROSION RESISTANCE
The TF-S-120W flexible solar panel employs SunPower cells with a remarkable conversion efficiency of up to 24.4%. These panels are designed to operate within an ambient temperature range of -40℃ to +85℃, delivering a stable output that remains consistent over time. These panels are backed by a 5-year warranty and boast a service life of 20 years. Their durability and stable output enable them to maintain excellent performance even in adverse weather conditions.
Applications

RV

Home

Yacht

Frequently Asked Questions

Yes. It’s just that the power generation efficiency of solar panels will be reduced.

Yes. TF series flexible solar panel is designed with patented materials, combined with SunPower cells, and can be fully adapted to long-term walking after strict pedaling experiments. It will not cause cell rupture, and will not affect the warranty period.

This 120W flex solar panel is suitable for RVs, vans, caravans and yachts. It can also be installed on balcony to provide power to your home

TF series flexible solar panels use Sungold’s exclusive patented materials. The material allows solar panels to be greatly improved in terms of weather resistance, salt spray resistance, corrosion resistance and aging resistance.

5 years warranty. TF series flexible solar panels have service life of 20 years.

Specifications

Maximum power(Pmax)

135W

Open-circuit voltage(Voc)

26.2V

Voltage at Pmax(Vmp)

22.3V

Short-circuit current(Isc)

6.42A

Current at Pmax(Imp)

6.06A

Cells efficiency(%)

24.40%

The maximum system voltage

200V DC(IEC)

Power temperature coefficient

-0.270%/℃

Voltage temperature coefficient

-0.236%/℃

Current temperature coefficient

+0.058%/℃

Output power tolerance

±3%

Operating temperature

-40~85℃

Weight

2.33kg

Dimensions

1200*540*3mm

Warranty

5 years
