SGM2-180W
Sungold Powerful 180 Watt Solar Panel | Perfect for RVs

 RV’s solar system with Sungold SGM2-180W solar rigid panels, equipped with cutting-edge Half-cut cell technology on 182mm mono solar cells. Experience reduced interconnection losses and enjoy higher efficiency. This easy-to-install and virtually maintenance-free solar kit ensures reliable energy on your outdoor adventures. The anodized aluminum frame and sealed junction box make the solar PV module weatherproof for outdoor use. Invest in our 180W solar panel for enhanced performance and worry-free RV travels.

Suitable for Multiple Scenarios – Ideal for 12V off-grid applications, including RVs, rooftops, cabins, yachts, homes, fences, greenhouses, and LED lights.

make the most of every sunlight
Features
Durable & Strong
High Efficiency
Long-lasting Performance
Wide range of applications
High Efficiency

maximum power 180w at 22.70% efficiency.
Under the condition of sufficient sunlight, the conversion rate of the cell reaches 22.70%, Compared with conventional solar panels, it allows more direct sunlight to be converted to electrical power.

Flexible Design

Monocrystalline solar panels are lightweight and easy to handle, which makes them ideal for installation on roofs, RVs, yachts, and other locations where space is limited.

Durable & Strong
Monocrystalline solar panels are made from robust materials that are highly resistant to environmental factors like high winds, hail, and other forms of weather-related damage.
Wide range of applications

Meet multiple scenarios: yacht / RV / roof/tent / outdoor camping/balcony, etc. Use it for your RV when camping, or during beach trips with the family, either way, this monocrystalline panel provides you with the most efficiency per space.

Applications

balcony

rooftop

Yacht

Frequently Asked Questions
The output power of solar panels is mainly affected by light intensity, light angle, and shadow occlusion during the use of solar panels. Therefore, during daily use, the angle of illumination must be adjusted to prevent shadows, and the obstructions on the solar panel must be cleaned regularly, such as bird droppings, dust, and garbage. Such obstructions may cause the solar panel to not output at all.
yes, surely you can install on roof of your vehicle for charge the AGM car battery.
yes, we support two same solar module connect in parallel or series to increase the power, the system voltage is 1000V.
would recommend use this solar panel to charge the battery, and run your radio with the battery.
yes, you can, the USB power comes from the battery, and the controller will protect the battery from overcharging and overloading.
The solar panel uses tempered glass to protect the cells, naturally, falling acorns will not damage it.
Specifications

Maximum power(Pmax)

180W

Open-circuit voltage(Voc)

24.5V

Voltage at Pmax(Vmp)

20.9V

Short-circuit current(Isc)

9.04A

Current at Pmax(Imp)

8.62A

Cells efficiency(%)

22.70%

The maximum system voltage

1000V DC(IEC)

Power temperature coefficient

-0.42%/℃

Weight

10.10kg

Voltage temperature coefficient

-0.32%/℃

Current temperature coefficient

0.04%/℃

Output power tolerance

±3%

Operating temperature

-40~85℃

Size

1200*770*35mm

Warranty

10 years

Not sure what you needs
There are three things we need to determine what you will need for your solar generator
What type of solar panel do you need?
What size of solar panels and batteries will be needed
What is the total watts you will be needing and how with your generator be used?

Leave a Message

If you are interested in our products and want to know more details, please leave a message here and we will get back to you as soon as possible.
