SGF3-240W
Sungold Glass folding Solar Panel SGF3-240W


2*3*11 cells
mono 182 cells

240W

22.70%

-10℃-+60℃
Remarkable efficiency
Using grade A+ monocrystalline solar cells.
Glass folding solar panels have a higher surface area to volume ratio than traditional flat solar panels, which can result in improved energy production.
Durability
Foldable design, Reailable quality
Glass folding solar panels are made of tempered glass, which is stronger and more durable than traditional plastic solar panels. This makes them more resistant to damage from hail, wind, and other environmental factors.
Easy to use
Plug and play solar kit
complete kit includes a 180W solar suitcase a 20A waterproof charge controller, and alligator clips.Compatible with multiple kinds of 12V batteries, easily add to your existing system.
Want to Quote
Maximum power(Pmax)
180W
Cells efficiency(%)
22.70%
Output power tolerance
±3%
Backplane Color
Black
Current at Pmax(Imp)
10.59A
Module dimension
1690*890*2mm
Warranty
5 years
Open-circuit voltage(Voc)
24.0V
Operating temperature
-10℃-+60℃
Junction box
PV-HX025A/PV-HX025B
Voltage at Pmax(Vmp)
20.5V
Power temperature coefficient
-0.38%/℃
Current at Pmax(Imp)
2.75A
Packing
1 piece into 1 bubble bag and then into a carton (K434K paper), 10 small cartons into a large carton (K636K paper)
Voltage at Pmax(Vmp)
IP65
Weight
14.3kg
Short-circuit current(Isc)
2.91A
Voltage temperature coefficient
-0.36%/℃
Solar cell
210 mono solar cells
Current temperature coefficient
+0.07%/℃
