SG-TF-M-220W

Sungold solar flex TF-M-220W

TF-M-200w flexible solar panel product has passed Sungold’s tread test. The reliability and stability of the product have been verified, and it also proves that Sungold’s self-developed patented material has good protection for the solar cells, and also lays a solid foundation for the 5-year warranty.TF-M-200W flexible solar panel is made of A-grade monocrystalline 166 solar cells with a conversion efficiency of 22.8%, which is ideal for off-grid environments such as RVs and ships.
make the most of every
Features
Adopt Polymer Composite Material
High conversion efficiency
Lightweight and Durable
Anti-trampling
ANTI-TRAMPLING
SG-TF-M-200W flexible solar panels have passed long-term trampling tests. Ambient temperature -40~85℃, high impact resistance and weather resistance 5 years warranty, 10 years service life, stable output and trustworthy quality, keep excellent performance even in extreme weather
High conversion efficiency

Sungold TF series flexible solar panels cover monocrystalline silicon solar cells with a technology that truly enables a new glass-free, thin, lightweight, and flexible solar panel. Combined with a durable ETFE surface material that maximizes sunlight absorption and higher solar energy conversion efficiency, it empowers sustainable living.

Lightness and impact resistance

Lightweight and impact resistant, corrosion resistant and strong UV resistant, protect solar panels and keep stable output at the same time install. The ultimate in lightness and flexibility, it can fit any irregular surface.

Long life with durability
TF series flexible solar panels have passed long-term trampling tests. The ETFE surface material also greatly enhances the value of the solar panel and can be used in extreme weather.Ambient temperature -40~85℃, high impact resistance and weather resistance 5 years warranty, 10 years service life, keep excellent performance even in extreme weather
Applications

RV

Home

Yacht

Frequently Asked Questions

A half cell is obtained by cutting a standard cell in half. The half-cell module can reduce the loss of power generation due to shading. At the same time, the half cell can reduce the power loss of the whole PV module.

TF series flexible solar panels use Sungold’s exclusive patented materials. The material allows solar panels to be greatly improved in terms of weather resistance, salt spray resistance, corrosion resistance and aging resistance.

5 years warranty. TF series flexible solar panels have service life of 20 years

Sungold offers 55W, 110W, 200W, 220W, 245W, 270W light mono flexible solar panels to meet all your needs

ETFE material. ETFE material has the characteristics of weather resistance, corrosion resistance and aging resistance. ETFE material also has extremely high light transmission.

Specifications

Rated Power

220W

Open-circuit voltage(Voc)

23.3V

Voltage at Pmax(Vmp)

19.8V

Short Circuit Current

12.00A

Current at Pmax(Imp)

11.12A

Cells efficiency(%)

22.80%

The maximum system voltage

600V DC(IEC)

Power temperature coefficient

-0.38%/℃

Voltage temperature coefficient

-0.36%/℃

Current temperature coefficient

+0.07%/℃

Output power tolerance

±3%

Operating temperature

-40~85℃

Weight

4.08kg

Dimensions

1610*710*2mm

Warranty

5 years
